Automatic Dispensing Unit PT317R6

The device is intended for the exact batching of radiopharmaceuticals into the syringe automatically. Its purpose is to facilitate, improve and speed up batching the activity together with substantial restriction of an untoward effect of irradiation.

Safe and easy individual dose preparation

  • Prepare an individual dose by just a couple of clicks! The dose will be ready within 1 minute with the accuracy better than 3 %.
  • The built-in measuring system measures the activity in the syringe directly during the dose preparation process and displays it on the control PC screen.
  • The activity remaining in mother vial is calculated and displayed similarly.
  • PET doses can be prepared into 3ml, 5ml and 10ml syringes.

Video download    download

Shielding Parameters
  • The vial shielded by eqv. of 68mm Pb - Combination of W and Pb shield
  • Syringes shields - range from 8 to 11mm W
Tungsten Container PT318R2

Specially designed tungsten container fits the packaging set Type A PT314R2 for RF transportation. Using this solution eliminates the unshielded manipulation with an activity containing vial.

Highly Cost Effective
  • Combination of W and Pb shielding materials
  • Vial in a slanted position - no waste of RF (patented solution)
  • Only the standard consumables are used (BBraun or others)
  • No need to use any special disposable kits
  • Quick and easy wastes handling (only two needles and a vial)
  • Reasonable level of automation
  • Minimum time for the first dose set up needed, max. 3 min.
  • Automatic daily QC procedure with built in check emitter
Intuitive and User-friendly Software

Software continuously displays the remaining activity in the vial (calculated value). Automatic linearity and stability tests - check emitter incorporated in the device body. The software will recommend a value of individual dose according to the patient’s weight or BMI based on preset specifications. Selection of automatic, semiautomatic or manual modes.

Consumables for One Vial
  • 1x BBraun Spinocan 0,90 x 88mm; G20
  • 1x BBraun Sterican 0,80 x 120mm; G21
Technical Specifications
  • Dose accuracy ±3%
  • Dose range 35 - 1800 MBq
  • Max. vial volume 25 ml
  • Max. activity in the vial 20 GBq
  • Max. concentration 1500 MBq/ml
  • Radiopharmaceuticals All PET
Dimensions
  • Height 418 mm
  • Width 411 mm
  • Length 299 mm
  • Weight 84 kg
